K-DAF/1120-MS {Exclusive}

May 8, 2018

K-DAF/1120-MS {Exclusive}

Kateel

K-DAF/1120-MS – Disc Brakes

Max Braking force : 104000 N

Min braking force : 96000 N

Maximum clamping force : 130000 N

Minimum clamping force : 120000 N

Operating pressure normal/max : 190 bar max

Air / oil consumption : 200cc

Pad width : 200mm

Pad area : 37224 sqmm

Maximum allowable wear of brake pad : 5 mm

Nominal Co-efficient of friction : 0.3 µ

Max Air gap : 1 mm

Weight : 250 kgs

Description

K-DAF/1120-MS is used with a Brake Disc of thickness 15 / 25 mm.

The Kateel range of hydraulic brakes use a specially formulated hydraulic oil (Hydrol 68) to deliver the desired hydraulic pressure. These hydraulic brakes require a hydraulic power unit to operate the brake. Variable braking torque can be achieved by regulating the hydraulic pressure as shown in the chart.

Features

Sturdy design.
Easy mounting.
Low maintenance
Less space consumption.
Suitable for wet, dusty and corrosion aggressive environments.
Cost effective.

Options

Manual release
Brake on / off indicator
Organic / sintered metal brake pads
Hydraulic power pack

Application Area

Steel Industries.
Conveyor application
Wind Turbine
Special Purpose Machines
Bulk Material Handling
Equipments
Mines
Cement Mills

View Data Sheet

May 1, 2018

K-DAF-212-DS

Kateel

K-DAF-212-DS

Max Braking force : 19200 N

Min Braking force : 18000 N

Maximum clamping force : 25840 N

Minimum clamping force : 24400 N

Operating pressure normal/max : 2100 bar max

Air / oil consumption : 200cc

Pad width : 70mm

Pad area : 4540 sqmm

Maximum allowable wear of brake pad : 5 mm

Nominal Co-efficient of friction : 0.3 µ

Max Air gap : 1 mm

Weight : 20 kgs

Description

Features

Sturdy design.
Easy mounting.
Low maintenance
Less space consumption.
Suitable for wet, dusty and corrosion aggressive environments.
Cost effective.

Options

Manual release
Brake on / off indicator
Organic / sintered metal brake pads
Hydraulic power pack

Application Area

Steel Industries.
Conveyor application
Wind Turbine
Special Purpose Machines
Bulk Material Handling
Equipments
Mines
Cement Mills

View Data Sheet

May 1, 2018

K-DAF-212-MS

Kateel

K-DAF-212-MS

Max Braking force : 9600 N

Minimum clamping force : 12920 N

Operating pressure normal/max : 200 bar max

Air / oil consumption : 200cc

Pad width : 70mm

Pad area : 4540 sqmm

Maximum allowable wear of brake pad : 5 mm

Nominal Co-efficient of friction : 0.3 µ

Max Air gap : 1 mm

Weight : 20 kgs

Description

Features

Sturdy design.
Easy mounting.
Low maintenance
Less space consumption.
Suitable for wet, dusty and corrosion aggressive environments.
Cost effective.

Options

Manual release
Brake on / off indicator
Organic / sintered metal brake pads
Hydraulic power pack

Application Area

Steel Industries.
Conveyor application
Wind Turbine
Special Purpose Machines
Bulk Material Handling
Equipments
Mines
Cement Mills

View Data Sheet

May 1, 2018

KG-PA-250

Kateel

KG-PA-250

Max Braking force : 26804 N

Min braking force : 24124 N

Maximum clamping force : 33506.89 N

Minimum clamping force : 30156.29 N

Operating pressure normal/max : 50 bar max

Air / oil consumption : 20cc

Pad width : 110mm

Pad area : 40,800 sqmm

Maximum allowable wear of brake pad : 5 mm

Nominal Co-efficient of friction : 0.4 µ

Max Air gap : 0.5 mm

Description

Features

Sturdy design.
Easy mounting.
Low maintenance
Less space consumption.
Suitable for wet, dusty and corrosion aggressive environments.
Cost effective.

Options

Manual release
Brake on / off indicator
Organic / sintered metal brake pads
Hydraulic power pack

Application Area

Steel Industries.
Conveyor application
Wind Turbine
Special Purpose Machines
Bulk Material Handling
Equipments
Mines
Cement Mills

April 27, 2018

K-DAF/1120-DS {Exclusive}

Kateel

K-DAF/1120-DS – Disc Brakes

Max Braking force : 208000 N

Min braking force : 176800 N

Maximum clamping force : 260000 N

Minimum clamping force : 221000 N

Operating pressure normal/max : 190 bar max

Air / oil consumption : 200cc

Pad width : 200mm

Pad area : 37224 sqmm

Maximum allowable wear of brake pad : 5 mm

Nominal Co-efficient of friction : 0.3 µ

Max Air gap : 1 mm

Weight : 250 kgs

Description

K-DAF/1120-DS to be used with variable Brake Disc of thickness 15 / 25 mm.

Features

Sturdy design.
Easy mounting.
Low maintenance
Less space consumption.
Suitable for wet, dusty and corrosion aggressive environments.
Cost effective.

Options

Manual release
Brake on / off indicator
Organic / sintered metal brake pads
Hydraulic power pack

Application Area

Steel Industries.
Conveyor application
Wind Turbine
Special Purpose Machines
Bulk Material Handling
Equipments
Mines
Cement Mills

View Data Sheet

April 27, 2018

K-DAF/1120-MS {Exclusive}

Kateel

K-DAF/1120-MS – Disc Brakes

Max Braking force : 78000 N

Min braking force : 72000 N

Maximum clamping force : 130000 N

Minimum clamping force : 120000 N

Operating pressure normal/max : 190 bar max

Air / oil consumption : 200cc

Pad width : 200mm

Pad area : 59600 sqmm

Maximum allowable wear of brake pad : 5 mm

Nominal Co-efficient of friction : 0.3 µ

Max Air gap : 1 mm

Weight : 190 kgs

Description

K-DAF/1120-MS is used with a Brake Disc of thickness 15 / 25 mm.

Features

Sturdy design.
Easy mounting.
Low maintenance
Less space consumption.
Suitable for wet, dusty and corrosion aggressive environments.
Cost effective.

Options

Manual release
Brake on / off indicator
Organic / sintered metal brake pads
Hydraulic power pack

Application Area

Steel Industries.
Conveyor application
Wind Turbine
Special Purpose Machines
Bulk Material Handling
Equipments
Mines
Cement Mills

April 27, 2018

KF-HF-700

Kateel

KF-HF-700 – Disc Brakes

Max Braking force : 11811 N

Min braking force : 11220 N

Maximum clamping force : 14764 N

Minimum clamping force : 14026 N

Operating pressure normal/max : 50 bar max

Air / oil consumption : 20cc

Pad width : 90mm

Pad area : 22,500 sqmm

Maximum allowable wear of brake pad : 5 mm

Nominal Co-efficient of friction : 0.4 µ

Max Air gap : 0.5 mm

Weight : 15 kgs

Description

Kf-HF-700 is used with a Brake Disc of thickness 15 / 25 mm.

Features

Sturdy design.
Easy mounting.
Low maintenance
Less space consumption.
Suitable for wet, dusty and corrosion aggressive environments.
Cost effective.

Options

Manual release
Brake on / off indicator
Organic / sintered metal brake pads
Hydraulic power pack

Application Area

Steel Industries.
Conveyor application
Wind Turbine
Special Purpose Machines
Bulk Material Handling
Equipments
Mines
Cement Mills

View Data Sheet

April 27, 2018

KC-PA-150

Kateel

KC-PA-150 – Disc Brakes

Max Braking force :4391 N
Min Braking force : 4172 N
Max clamping force : 5489 N
Min clamping force : 5215 N
Operating pressure normal/max :5 / 7 bar
Air / oil consumption: 300cc
Pad width : 46mm
Pad area : 11,400 sq mm
Max allowable wear of brake pad : 5mm
Nominal Co-efficient of friction : 0.4 µ
Max Air gap : 0.5mm
Weight: 8.5kgs

Description

KC-PA-150 is used with Brake Discs of thickness 13-15 / 25.4

The Kateel range of pneumatic brakes uses dry and compressed air at pressures up to 7 bar. These pneumatic brakes require a control valve which may be operated manually / by electric signal.

Features

Compact design.
Easy mounting.
Low maintenance
Less space consumption.
Suitable for wet, dusty and corrosion aggressive environments.
Cost effective.

Options

Brake on / off indicator.
Organic / sintered metal brake pads
Pneumatic control panel

Application Area

Steel Industries.
Cable Industries.
Paper Industries.
Wire Drawing Machine.
Tyre Industries.
Textile Machineries.
Sugar Centrifuge
Special Purpose Machines.

View Data Sheet

April 27, 2018

KB-PA-180

Kateel

KB-PA-180 – Disc Brakes

Max Braking force : 7761 N

Min Braking force : 7374 N

Max clamping force : 9702 N

Min clamping force : 9217 N

Operating pressure normal/max : 5 / 7 bar

Pad width : 46mm

Pad area : 5700 sq mm

Max allowable wear of brake pad : 5mm

Nominal Co-efficient of friction : 0.4 µ

Max Air gap : 0.5mm

Weight: 9kgs

Description

KB-PA-180 is used with Brake Discs of thickness 13-15 / 25.4

The Kateel range of pneumatic brakes uses dry and compressed air at pressures up to 7 bar. These pneumatic brakes require a control valve which may be operated manually / by electric signal.

Features

Compact design.
Easy mounting.
Low maintenance
Less space consumption.
Suitable for wet, dusty and corrosion aggressive environments Cost effective.

Options

Brake on / off indicator.
Organic / sintered metal brake pads
Pneumatic control panel

Application Area

Steel Industries.
Cable Industries.
Paper Industries.
Wire Drawing Machine.
Tyre Industries.
Textile Machineries.
Sugar Centrifuge
Special Purpose Machines.

View Data Sheet

February 17, 2018

KU-PA-050

Kateel

KU-PA-050 – Disc Brakes

Max Braking force : 1078 N
Max clamping force : 2695 N

Operating Pressure: 5/7 bar
Pad width : 30 mm
Pad area : 310 sqmm
Max allowable wear of brake pad : 5mm
Nominal Co-efficient of friction : 0.4 µ
Max Air gap : 0.5mm

Description

KU-PA-050 is used with Brake Discs of thickness 10 to 12 mm.

The Kateel range of pneumatic brakes uses dry and compressed air at pressures up to 7 bar. These pneumatic brakes require a control valve which may be operated manually / by electric signal.

Features

Compact design.
Easy mounting.
Low maintenance
Suitable for wet, dusty and corrosion aggressive environments.
Cost effective.

Options

Brake on / off indicator.
Organic / sintered metal brake pads
Pneumatic control panel
Scoop switch for brake on and off.

Application Area

Steel Industries.
Cable Industries.
Paper Industries.
Nuclear Power
Special Purpose Machines.
Test Rings

View Data Sheet
